Ⅰ Specification Parameter: Model No Power Supply Capacity Net Weight Measurement IP-FGJ-100C AC220V,50HZ, 370W 1000 cans/h 27kg/set 200×350×620mm   Ⅱ Operation Manual: 1. Keep the machine on flat platform to avoid inclination. 2. Get power connected. Press the red back button, screen lights. 3. Trial operation: Press the green start button, the instruction light and LED light will turn on if the machine works well. 4. Put the can with top lid on the tray. 5. Move the hand lever to the left until it is tight. 6. Start the machine. It would stop automatically when seaming finishes. 7. Move the hand lever to the right, loose and take out the finished can. 8. If something wrong happens, press the red emergency button. 9. Press the emergency button for 10 seconds, the counting quantity will be reset.

834 2PC Round Food Tin Cans Empty For Fish Packaging Can Body Picture No. Item Spec 1  Material  TFS, T4BA 2  Diameter  307x105 3  Can Height  34.10 ± 0.10mm 4  Thickness  0.18mm 5  Internal Lacquer  Aluminized Organosol 6  External Lacquer  Epoxy Amino - Plain or printed 7  Flange Width  2.8 ± 0.20mm 8  Internal Diameter  83.3 ± 0.10mm Double Seam Specification Picture No. Item Spec.   1  Countersink  3.30 ⁓ 3.50mm 2  Seam Thickness  1.20 ⁓ 1.40mm 3  Seam Length  2.80 ⁓ 3.00mm 4  Body Hook  1.80 ⁓ 2.10mm 5  Cover Hook  1.80 ⁓ 2.10mm 6  Actual Overlap  >1.02mm 7  %Overlap  >50 8  %Free Wrinkle  >60 Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine INTERPACK offer a wide choice of Empty Tuna Cans. View more information at interpackgroup.net.

307# Easy Open Tin Can Lid Tin lids has two styles usually: standard normal end/lid and easy open end.. Standard normal end/lid must be opened by can-opener. Easy open lid is much more easily. You only need to pull the easy open ring, and then the food will be available. Picture No. Item Spec 1  Thickness  0.18mm 2  The volume of tin  2.8/2.8 3  Internal Diameter 93.00-93.40 4  Round edge height 1.70-2.10 5 Surface depth  0.80-1.10 6  Open force  15-30 7 Full open force  50-90 Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

340# Food Grade Luncheon Meat Metal Tin Can About 200 years ago, tin can was invented for food packing and storage. Until now, tin can packaging is still one of the important method of food packaging. 3 piece can is able to be separated to round can and rectangular can in shape, and be separated to be vegetable can, meat can, fish can in usage. Interpack Group has 60 production lines in 5 branch factories to produce normal 3 piece cans， which makes it reach annual capacity of 3 billion. Besides, Interpack Group is able to provide machines such as seaming machine, filling machine, retort pot and technical support such as project design. Picture No. Item Spec 1  Size  94.2x47x92±0.10mm 2  Material  TPS,T2.5 CA 3  Tin Coating  2.8/2.8 4  Volume  340g 5  Thickness  0.22mm 6  External printing  CMYK 7  Internal Lacquer  Meat Release Aluminum 8  Used  Luncheon Meat Can and so on Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

Empty Coffee Metal Tin Can For Beverage Canning 180ml About 200 years ago, tin can was invented for food packing and storage. Until now, tin can packaging is still one of the important method of food packaging. 3 piece can is able to be separated to round can and rectangular can in shape, and be separated to be vegetable can, meat can, fish can in usage. Interpack Group has 60 production lines in 5 branch factories to produce normal 3 piece cans， which makes it reach annual capacity of 3 billion. Besides, Interpack Group is able to provide machines such as seaming machine, filling machine, retort pot and technical support such as project design. Can Body Picture No. Item Spec 1  Material  TPS, T4CA 2  Diameter  202x314 3  Can Height  104.0 ± 0.10mm (Adjustable) 4  Thickness  0.18mm 5  Internal Lacquer  Gold Organosol 6  External Lacquer  Epoxy Amino - Plain or printed 7  Flange Width  2.8 ± 0.20mm 8  Internal Diameter  65.3 ± 0.10mm Double Seam Specification Picture No. Item Spec.   1  Seaming Length  2.70±0.10mm 2  Body Hook  1.95±0.10mm 3  Cover Hook  1.95±0.10mm 4  Seam Thickness  1.15±0.05mm 5  Overlap Percent  ≥60% 6  Tightness Rating  ≥70% Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

Wholesale Food Grade Metal Can For Food Packaging About 200 years ago, tin can was invented for food packing and storage. Until now, tin can packaging is still one of the important method of food packaging. 3 piece can is able to be separated to round can and rectangular can in shape, and be separated to be vegetable can, meat can, fish can in usage. Interpack Group has 60 production lines in 5 branch factories to produce normal 3 piece cans， which makes it reach annual capacity of 3 billion. Besides, Interpack Group is able to provide machines such as seaming machine, filling machine, retort pot and technical support such as project design. INTERPACK provides a variety of Food Grade Metal Cans for food packaging. Can Body Picture No. Item Spec 1  Material  TPS, T4CA 2  Diameter  401x411 3  Can Height  113.0 ± 0.10mm (Adjustable) 4  Thickness  0.16mm 5  Internal Lacquer  Gold Organosol 6  External Lacquer  Epoxy Amino - Plain or printed 7  Flange Width  2.7 ± 0.10mm 8  Internal Diameter  72.9 ± 0.15mm Double Seam Specification Picture No. Item Spec.   1  Seaming Length  2.70±0.10mm 2  Body Hook  1.85±0.10mm 3  Cover Hook  1.85±0.10mm 4  Seam Thickness  1.15±0.05mm 5  Overlap Percent  ≥60% 6  Tightness Rating  ≥70% Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

Empty BPA Free Fish Tin Can with External Printing About 200 years ago, tin can was invented for food packing and storage. Until now, tin can packaging is still one of the important method of food packaging. 3 piece can is able to be separated to round can and rectangular can in shape, and be separated to be vegetable can, meat can, fish can in usage. Interpack Group has 60 production lines in 5 branch factories to produce normal 3 piece cans， which makes it reach annual capacity of 3 billion. Besides, Interpack Group is able to provide machines such as seaming machine, filling machine, retort pot and technical support such as project design. Can Body Picture No. Item Spec 1  Material  TPS, T4CA 2  Diameter  300x201 3  Can Height  52.0 ± 0.10mm (Adjustable) 4  Thickness  0.18mm 5  Internal Lacquer  Gold Organosol 6  External Lacquer  Epoxy Amino - Plain or printed 7  Flange Width  2.8 ± 0.10mm 8  Internal Diameter  98.9 ± 0.10mm Double Seam Specification Picture No. Item Spec.   1  Seaming Length  2.80~3.00mm 2  Body Hook  1.80~2.10mm 3  Cover Hook  1.80~2.10mm 4  Seam Thickness  1.20~1.40mm 5  Overlap Percent  ≥60% 6  Tightness Rating  ≥70% Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

Factory direct sale square tin cans 311 2 piece can is made on punching machine, one piece tinplate sheet will be cut to be round shape firstly and then be punched vertically. 2 piece can usually has aluminum internal lacquer and used to pack meat and fish. 2 piece can is stack-able because the bottom diameter is a little smaller than top. It is able to make printing external surface, but it’s a little more difficult than 3 piece can. Anyway, Interpack Group can do it perfectly. Can Body Picture No. Item Spec 1  Material  TFS, T2.5BA 2  Diameter  L106.6*W63*H28mm 3  Can Height  68.0 ± 0.10mm (Adjustable) 4  Thickness  0.20mm 5  Internal Lacquer  12g Aluminum Organosol 6  External Lacquer  5g Gold lacquer Double Seam Specification Picture No. Item Spec.   1  Width  69.40±0.25mm 2  Length  113.35±0.25mm 3  Curl Height  2.00±0.25mm 4  Countersink Depth  3.25±0.20mm 5  Seaming Compound Weight  95±15mm 6  Compressive Strength  ≥160mm 7  Pop strength  15-30mm 8  Tear trength  60-100mm  9  match up diameter of the can  103.85×59.85mm Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

860# BPA Free Empty Tin Can For Pig Meat Packing About 200 years ago, tin can was invented for food packing and storage. Until now, tin can packaging is still one of the important method of food packaging. 3 piece can is able to be separated to round can and rectangular can in shape, and be separated to be vegetable can, meat can, fish can in usage. Interpack Group has 60 production lines in 5 branch factories to produce normal 3 piece cans， which makes it reach annual capacity of 3 billion. Besides, Interpack Group is able to provide machines such as seaming machine, filling machine, retort pot and technical support such as project design. Can Body Picture No. Item Spec 1  Material  TPS, T4CA 2  Diameter  211x211 3  Can Height 60.0 ± 0.10mm (Adjustable) 4  Thickness  0.18mm 5  Internal Lacquer  Gold Organosol 6  External Lacquer  Epoxy Amino - Plain or printed 7  Flange Width  2.8 ± 0.20mm 8  Internal Diameter 85.3 ± 0.10mm Double Seam Specification Picture No. Item Spec.   1  Seaming Length  2.70±0.10mm 2  Body Hook  1.95±0.10mm 3  Cover Hook  1.95±0.10mm 4  Seam Thickness  1.15±0.05mm 5  Overlap Percent  ≥60% 6  Tightness Rating  ≥70% Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

Factory direct sale square tin cans 311 2 piece can is made on punching machine, one piece tinplate sheet will be cut to be round shape firstly and then be punched vertically. 2 piece can usually has aluminum internal lacquer and used to pack meat and fish. 2 piece can is stack-able because the bottom diameter is a little smaller than top. It is able to make printing external surface, but it’s a little more difficult than 3 piece can. Anyway, Interpack Group can do it perfectly. Can Body Picture No. Item Spec 1  Material  TFS, T2.5BA 2  Diameter  L106.6*W63*H28mm 3  Can Height  68.0 ± 0.10mm (Adjustable) 4  Thickness  0.20mm 5  Internal Lacquer  12g Aluminum Organosol 6  External Lacquer  5g Gold lacquer Double Seam Specification Picture No. Item Spec.   1  Width  69.40±0.25mm 2  Length  113.35±0.25mm 3  Curl Height  2.00±0.25mm 4  Countersink Depth  3.25±0.20mm 5  Seaming Compound Weight  95±15mm 6  Compressive Strength  ≥160mm 7  Pop strength  15-30mm 8  Tear trength  60-100mm  9  match up diameter of the can  103.85×59.85mm Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine

330ml Empty Aluminum Can for Drink From the name, we can know that aluminum can is made of aluminum, it is two piece can and usually used for drink and beer packing. The top lid is usually SOT or RPT type. Can Body Picture No. Item Spec 1  Material  Aluminum 2  Can Type  206/211X408 3  Can Height  115.20±0.38 4  Thickness  0.18mm 5  Flange Width  2.18±0.25mm 6  Buckle resistance  >620kPa 7  Plug diameter(B)  57.4±0.25mm Packaging Other Terms: No. Item Spec. 1  Lead time  Around 30 days 2  Payment term  1) 100% L/C at sight  2) 30% by T/T in advance, balance against B/L copy  3) Other payment term Should be negotiated 3  Free service  Free seaming chuck (2 pc) 4  Other service  Cost effective seaming machine
